Canyon Ridge® Carriage House (5-Layer)

by

Crave the look of wood without the upkeep? Our 5-Layer faux wood door is constructed with an insulated steel base door for durability and topped with moisture-resistant composite cladding and overlays molded from natural wood boards.

Contact us about this product

Beautiful and unique

layers icon
5-Layer Construction

Steel + insulation + steel + composite cladding + composite overlay

lattice icon
Faux Wood-Look Composite

Faux wood composite cladding and overlay materials are molded from real wood pieces to reproduce the natural texture and intricate grain patterns of the species they emulate. Choose from Clear Cypress or Mahogany in a variety of paint and stain colors to create a custom look. The result is a stunning carriage house door you will enjoy for years to come.

magic wand icon
Design Customization

Fifteen carriage house designs with optional windows and decorative hardware. Available primed, painted or stained in 10 standard finishes. ColorBlast® custom paint colors also offered in 1,500 shades.

temperature icon
Insulation

2" Intellicore® polyurethane insulation with a thermal break. R-Value of 20.4.

wind blowing icon
Door Reinforcement

WindCode® door reinforcement product available for high wind load applications.

Environmental Assurance

Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:

  • California SB 1013
  • Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
  • Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
  • New Jersey A-5583/S-3919 – Greenhouse Gas Bill

Door Designs

Series 1

Canyon Ridge 5-Layer Design 01
Design 11 Design 11
Design 12 Design 12
Design 13 Design 13

Series 2

Design 21 Design 21
Design 23 Design 23

SERIES 2

Design 22 Design 22

Series 3

Design 31 Design 31
Design 32 Design 32
Design 33 Design 33
Design 34 Design 34
Design 35 Design 35
Design 36 Design 36
Design 37 Design 37
Design 38 Design 38

Top Sections

Series 1 & 2 Solid

Top11 TOP11

Double Top Sections

ARC1A-SOLID ARC1A-Solid-Double Door
ARC1A-WINDOW ARC1A-Windows-Double Door
ARC3A ARC3A-Windows-Double Door
ARC4A ARC4A-Windows-Double Door
ARC13A ARC13A-Windows-Double Door
ARC14A ARC14A-Windows-Double Door

Series 1 & 2 Window Designs

REC11 REC11
REC13 REC13
REC14 REC14
SQ23 SQ23
SQ24 SQ24
ARCH1 ARCH1
ARCH3 ARCH3
ARCH4 ARCH4
ARCH13 ARCH13
ARCH14 ARCH14

Series 1 & 2 SOLID

TOP12 TOP12
TOP13 TOP13
ARCH1 ARCH1

Colors

Natural finish Natural Finish
Medium Medium Finish
Dark Dark Finish
Walnut Walnut Finish
Slate Slate Finish
Espresso finish Espresso Finish
Black Black Finish*
White White Finish*
Primed Primed (No Finish)
Bronze Bronze*
Charcoal Charcoal*
Request Color Samples

*Available on select models.
Black, white, bronze and charcoal only available in Mahogany.
Two-tone option available. One color for the base layer (steel) and one color for the top layer (composite overlay).
Custom color available through ColorBlast® program.

Hardware Designs

Plates

Spade Step Plate Spade Step Plate
Spear Step Plate Spear Step Plate
Colonial Step Plate Colonial Step Plate

Handles

Hardware Spade Lift Handles
(included)
Hardware Spear Lift Handles
Hardware Colonial Lift Handles
Hardware Decorative Lift Handles
Hardware Ring Door Knocker
Hardware Escutcheon Plates
Hardware Twisted "L" Handles

Hinges

Spade Strap Hinge Spade Strap Hinge
Spear Strap Hinge Spear Strap Hinge
Colonial Strap Hinge Colonial Strap Hinge

Canyon Ridge® Carriage House (5-Layer) garage doors are built with a strong steel base door topped with low-maintenance moisture-resistant composite overlays that won't rot, warp or crack.

Canyon Ridge 5-Layer Cutaway

  1. Composite Overlay
  2. Composite Cladding
  3. Steel
  4. 2" Intellicore® Polyurethane Insulation
  5. Steel

Intellicore® Insulation

Warmer. Quieter. Stronger.
Garage doors featuring Intellicore insulation technology represent the ultimate smart choice for homeowners. Clopay’s Intellicore is a proprietary polyurethane foam that is injected into a garage door, expanding to fill the entire structure. The result is a door with incredible strength, energy efficiency, and durability.

Additional Features

  • Rust-Prevention System: Steel skins are protected with a tough, multi-layer coating system, including hot-dipped galvanizing, a protective metal oxide pretreatment, then a baked-on primer and top coat.
  • Replaceable vinyl bottom weather seal in a rust-resistant aluminum retainer helps keep out air and water.
  • A patented Safe-T-Bracket® prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension
  • All Intellicore® insulated doors come standard with 10-ball nylon rollers and heavy-duty 14-gauge steel hinges.
  • Product complies with 2015 IECC air infiltration requirement of 0.40 cfm/ft2 or less (IECC, Section C402.5.2)
  • Window grilles are removable for easy cleaning.
